Ceramic Fiber Fabric
Ceramic fabric is weaved by ceramic fiber yarn. Ceramic cloth with FG or wire can also be finsihed with heat treatment, aluminum foil, vermiculite coated. It is an ideal refractory material for furnace, boiler,oven insulation. Compared with fiberglass, ceramic fiber fabric is excellent resistance to thermal shock, corrossive chemical attack and vibrant movement. All the ceramic textiles is composed of approx 16% organic fibers added during ceramic yarn spun. Ceramic cloth is a good alternative for silica fabric.
Features
Outstanding high temperature resistance rating to 1000℃
Excellent performance on fire and thermal shock
Good tensile strength, vibration resistance
Good chemical, water hydration resistance
Application
Furance, oven heat zone insulation; Fabric expansion joint; Removable insulation jacket; Welding blanket
| Item | Yarn density, ends/cm | Thickness, mm | Area weight, g/m2 | Reinforce material | |
| R800 | 5.8 | 2.8 | 1.50 | 850 | Fiberglass |
| R1000 | 6.0 | 3.0 | 2.0 | 1000 | Fiberglass |
| R1400 | 4.5 | 2.1 | 3.0 | 1400 | Fiberglass |
| R800W | 5.8 | 2.8 | 1.50 | 850 | S.S Wire |
| R1000W | 6.0 | 3.0 | 2.0 | 1000 | S.S Wire |
| R1400W | 4.5 | 2.1 | 3.0 | 1500 | S.S Wire |
| R2500W | 5.0 | 2500 | Fiberglass/Wire | ||
Organic fiber: Polyester/Rayon fiber
Composition
| Ceramic yarn bulk wool composition | |
| Al2O3 | ≥45 |
| SiO2 | ≥54 |
| Fe2O3 | ≤0.5 |
| TiO2 | -- |
| Na2O | ≤0.2 |
| ZrO2 | -- |
| Temperature classification ℃ | 1260 |
| Non fiber content, % | ≤35 |
| Melting point, ℃ | 1575 |
| Fiber diameter, um | 3~5 |
| Shot content, % (Dia≥0.212mm) | ≤15 |
| Moisture, % | ≤3 |
| Color | White |
Packing:
Roll length: 30 meters or 10meters
One roll one polybag
20cartons per pallet
 |
 |
 |
|
Fiber forming |
Textile woven, knitting, braiding |
Fabric coating |
Why cloose us:
-
Top priority:
Complete and matured quality control and assurance experience. ISO9001-2008 certification. Our Promise:
NEVER REDUCE QUALTY FOR PROFIT
NEVER REDUCE QUALTY FOR HIGHER COST
100% RESPONSIBLE FOR OUR QUALITY -
Price and term:
Low price level for products range raw yarn to finished products. -
Feedback:
Shortest time reaction to inquiry, production state, delivery state, custom clearance supports and complaints. -
Support:
Project involved, new products development and investment.
FAQ:
-
What is products of EAS?EAS produces single fiberglass yarn, high temperature sewing threads, fiberglass woven fabrics, coating fabrics and fabrics finish. If necessary, EAS will buy other yarns for specific textiles request.
-
EAS provide all the products in the website?This website is one of EAS’s promotional channels. For special textiles or short production capacity, EAS will provide raw materials (Like fiberglass yarns and fabrics) and look for reliable OEM service in the condition of quality assurance.
